The WiFi Gateway Pro is our latest product. It provides a wide range of operating options.
This Gateway receives messages from the Wireless RF sensors supporting both RF2 (2-character ID) and RF4 (4-character ID) and uses secure networking to send them to the JemRF Monitor servers.
The WiFi Gateway Pro features a built-in MQTT Agent that publishes sensor values to an MQTT Broker, supporting a wide range of custom applications. It also supports MQTT Autodiscovery for Home Assistant, making integration a simple point-and-click add.
The WiFi Gateway Pro setup uses a similar internal WiFi configuration process for both the older WiFi Gateway and WiFi Sensor devices.
-
It receives sensor readings from the RF sensors and forwards the readings to the JemRF Monitoring service, a server of your own, and a concurrent MQTT broker.
-
Connects to your local WiFi for Internet connection.
-
Supports secure message sending to Monitor.JemRF.com or a custom server.
-
It supports an MQTT client-to-broker connection to forward data to custom servers. MQTT data formats are text or JSON.
-
Can be configured using Static IP or DHCP.
-
It can be configured and managed via an internal WEB server or over your local WiFi.
-
Provides the option to convert Celsius to Fahrenheit.
-
Provides the option to change the RF Receiver channel (0-9).
Supports MQTT message formats
The WiFi Gateway Pro does not issue commands to the Wireless RF Sensors, except that it can send a message to change the sensor update interval when a sensor activates for the first time.
The WiFi Gateway Pro protocol does not work with the older Private Eye Server.
Installation:
-
Installation is easy; plug in a USB-C power adapter
-
The Gateway has an internal WiFi network for setup and monitoring.
-
Details and steps to put it online are in our illustrated guide
Specs:
-
Dimensions 74mm x 55mm x 28mm
-
Powered either by a USB-C cable, 2.5 amps
-
Operating Temperature is -30 °C to +46 °C. (-20°F to +115°F)
